AquiSense
PearlAqua
The PearlAqua is the world’s first UV-C LED product designed for water disinfection. This flagship system integrates state-of-the-art LEDs into a unique and compact design without the use of chemicals or mercury-based UV lamps.
The PearlAqua is 1 of 3 new platforms
Maximum Environmental Protection
PearlAqua offers the most advanced disinfection without any risk to the environment. Low power requirements and no harmful materials make the PearlAqua the best option.
Replaceable UVinaire®
UVinaire is a replaceable LED lamp module that is the heart of the PearlAqua. Easily replaced at the end of its 10,000 hour life, it includes a safety interlock switch and on-board data logging.
Point of Use Treatment
The PearlAqua can instantly deliver safe and clean water. The compact design is self-contained without the requirement for a separate control box as required with a traditional UV system. Performance Indicator External indication of lamp operation, and alarm conditions. Remote start/stop operation with unlimited cycles per day. Optional UV intensity sensor available.
Performance Indicator
External indication of lamp operation, and alarm conditions. Remote start/stop operation with unlimited cycles per day. Optional UV intensity sensor available.
Available Models and Sizes
The PearlAqua is available in three sizes and each unit is customizable. With flowrates ranging from 1.5 LPM to 12 LPM, there is a PearlAqua model to fit every flow.
Units are available with an optional power supply.
| 9D | 15E | 24G | |
|---|---|---|---|
| A | 73 [2.87] | 87 [3.42] | 127 [5.00] |
| B | 92 [3.62] | 105 [4.13] | 148 [5.83] |
| C | 100 [3.93] | 100 [3.93] | 140 [5.51] |
Certification
PearlAqua systems are compliant with NSF/ANSI-61 for material safety and NSF/ANSI-372 for lead-free compliance.
UV LED Technology Solves Common UV Maintenance Problems
UV LED Technology Solves Common UV Maintenance Problems
One of the greatest advantages of UV-C LED systems are its reduced need for cleaning and maintenance compared to mercury lamps:
| PearlAqua with UV-C LEDs* | Mercury Lamps | |
|---|---|---|
| 10 Year Maintenance Cost | $0 | $1,126 |
| System Cleaning Needs | Annually | Monthly |
| 10 Year Total Energy Cost | $10.97 | $130.67 |
* Numbers based on the PearlAqua 6D and generic UV system running 2.65 LPM, 2.5hrs/day.
AquiSense Technologies introduces PearlAqua, the world’s first commercial UV-C LED disinfection system, paving the way for superior performance and safer water treatment technology.
This millennial technology jumps over the hurdles of conventional mercury UV systems, such as constant maintenance, high operating temperatures, decay of the lamp for every on cycle, fragile systems etc.
Minimal Maintenance Needs
• Low component count means less failure points - less maintenance
• No complicated mechanical sleeve cleaning
Zero Temperature Influence
• Unlike the mercury lamps there is no heat transfer to water
• Does not promote biofouling development
Lower Energy Consumption
• The PearlAqua runs on DC power and has lower wattage
• Energy costs reduces by 80%
No Advanced Lamp Decay
• Mercury-based lamps decay at an advanced rate from frequent on/off
• UV-C LEDs can have a million on/off cycles without decay the LEDs
Hazard Free
• The PearlAqua uses UV-C LEDs instead of mercury
• Plus, there is no fear of exposure during use or replacement
